Product Details
Place of Origin: Wuhan
Brand Name: HE LASER
Certification: CE
Model Number: S4
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: 47999 USD
Packaging Details: wooden package
Delivery Time: within 30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 Sets per Month
Name: |
Fiber Laser Cutting Machine 4000W |
Condition: |
New |
Cutting Area: |
3000mm*1500mm |
Cutting Thickness: |
Depend On Materials |
Laser Power: |
1500W-4000W |
Dimension: |
8900*3200*2600mm |
Name: |
Fiber Laser Cutting Machine 4000W |
Condition: |
New |
Cutting Area: |
3000mm*1500mm |
Cutting Thickness: |
Depend On Materials |
Laser Power: |
1500W-4000W |
Dimension: |
8900*3200*2600mm |
S2 CYCLONE Series Shuttle Platform Fiber Laser Cutting Machine 1500-4000W
|
Thermal annealing steel bed, long service life
Large format and heavy machine body adopts frame structure welded by high quality steel to get excellent dynamic and static response characteristics. After welding, annealing, secondary aging treatment, precision processed by large gantry milling machine, it can ensure the good shock resistance, high rigidity and stability for the machine body. |
|
|
Unique “L” shaped beam
Unique “L” design of the beam, which has better deformation resistance at horizontal section and vertical orientation and higher rigidity. It also has the advantages of less weight, better dynamic performance. |
|
Big height of passing the beam
The max height which can pass the beam is 110mm, can cut the profiles with U and L shapes. |
|
|
Efficient communication performance
Front operator interface and electrical cabinet can reduce circuit interference. |
|
Modular assemble platform
Assemble frames can prevent thermal deformation effectively. It is convenient to replace the supports to longer the life of platform. |
|
|
Compensation structure for beam expansion
Can modify the precision deviation caused by environment, temperature change and working condition intelligently. |
| Model | TWIN612/R |
| IR Detector Performance | |
| Resolution | 640×512 |
| Pixel Size | 12μm |
| Spectral Range | 8~14μm |
| Typical NETD | ＜40mK |
| Image Processing | |
| Frame Rate | 25Hz/30Hz |
| Start-up Time | 6s |
| Analog Video | PAL/NTSC |
| Digital Video | YUV/BT.656/LVDS/USB2.0 |
| Image Display | 11 in Total (White Hot/Lava/Ironbow/Aqua/Hot Iron/Medical/Arctic/Rainbow1/Rainbow2/Red Hot/Black Hot) |
| Image Algorithm | NUC/3D/2D/DRC/EE |
| Electrical Specifications | |
| Standard External Interface | 50pin_HRS |
| Communication Interface | RS232/USB2.0 |
| Supply Voltage | 4~5.5V |
| Typical Power Consumption | 0.8W |
| Temperature Measurement | |
| Operating Temperature Range | -10℃~50℃ |
| Temperature Measurement Range | -20℃~150℃, 0℃~550℃ |
| Temperature Measurement Accuracy | Greater of ±2℃ or ±2% |
| SDK | Windows/Linux; Achieve Video Stream Analysis and Conversion from Gray to Temperature |
| Physical Characteristics | |
| Dimension (mm) | 25.4×25.4×35 (Without Lens) |
| Weight | 25g (Without Lens) |
| Environmental Adaptability | |
| Operating Temperature | -40℃～+70℃ |
| Storage Temperature | -45℃～+85℃ |
| Humidity | 5%~95%, non-condensing |
| Vibration | 5.35grms, 3 Axis |
| Shock | Half Sine Wave, 40g/11ms, 3 Axis, 6 Direction |
| Optics | |
| Optional Lens | Fixed Athermal: 13mm |
